High Efficiency 24W LED Microwave Sensor Lamp
This is a microwave sensor switch controlled LED light, the microwave sensor is built into the lamp, there are 54 high-brightness leds, a total power of 24 watts. When the light is on, the luminous flux will exceed 2500 lm and the lifetime will exceed 20,000 hours. We use this sensitive advanced sensor switch in lighting control, when a person is detected to enter, the light will quickly turn on and automatically turn off when the person leaves.
Model:PD-LED2053
Send Inquiry
Product Details
Microwave Sensor Light Instruction PD-LED2053
Summary
This is a microwave sensor switch controlled LED light, the microwave sensor is built into the lamp, there are 54 high-brightness leds, a total power of 24 watts. When the light is on, the luminous flux will exceed 2500 lm and the lifetime will exceed 20,000 hours. We use this sensitive advanced sensor switch in lighting control, when a person is detected to enter, the light will quickly turn on and automatically turn off when the person leaves.
Product size
●Please confirm with profession installation.
●Please cut off power supply before installation and removal operations.
●Make sure that you have cut off the power for safety purposes.
●Improper operation caused losses, the manufacturer does not undertake any responsibility.
This manual is for the current content programming of this product,there are any changes and modifications to the manufacturer without notice!
It is strictly forbidden to copy the contents of the instruction manual forany other purpose without the permission of the company.
Name of each part
Installation
Specification
Power source | 220-240VAC |
Power frequency | 50/60Hz |
Rated load | 24W Max. |
PF | ≥0.85 |
HF system | 5.8GHz CW electric wave,ISM wave band |
Time setting | 2mins |
Detection range | 4-5m (radii.) |
Light-control | <10LUX~2000LUX |
Detection angle | 360° |
Luminous flux | ≥2500lm |
Color temperature | 3000K/3500K/4000K/5000K/6000K |
Installation height | 2.5-4.5m (ceiling mount) |
Working temperature | -10°C~+40°C |
Lamp part |
|
LED quanlity | 54PCS |
LED specifications | 2835 |
Sensor information
Note: The installation height is different, and the detection range needs to be adjusted according to actual needs.
